Appendices Appendix C Pin Assignments
C-12 [CONFIDENTIAL] Qosmio G50 Maintenance Manual (960-683)
C.10 CN2600 PCI-E Mini CARD (W-LAN) interface connector (52-
pin)
Table C-10 PCI-E Mini CARD(W-LAN) interface connector (52-pin)
Pin No. Signal Name Pin No. Signal Name
1 PEWAKE-E3N 2 E3V
3 WCHDA1-P3P 4 GND
5 WCHCLK-P3P 6 P1V
7 MN1XRQ-P3N 8 NC
9 GND 10 NC
11 XPEWL-P0N 12 NC
13 XPEWL-P0P 14 NC
15 GND 16 NC
17 NC 18 GND
19 NC 20 WLRFON-S3N
21 GND 22 PLTRS3-E3N
23 ZERMN1-P1N 24 E3V
25 ZERMN1-P1P 26 GND
27 GND 28 P1V
29 GND 30 NC
31 ZETMN1-P1N 32 NC
33 ZETMN1-P1P 34 GND
35 GND 36 ZUSBP4-E3N
37 GND 38 ZUSBP4-E3P
39 E3V 40 MN1PRS-P3N
41 E3V 42 WMLED-E3P
43 GND 44 NC
45 NC 46 NC
47 NC 48 P1V
49 NC 50 GND
51 NC 52 E3V
1T
GND
2T
GND
