Appendix C Pin Assignments Appendices
Qosmio G50 Maintenance Manual (960-683) [CONFIDENTIAL] C-17
C.16 CN2801 Power connector (20-pin)
Table C-16 Power connector (20-pin)
Pin No. Signal Name Pin No. Signal Name
1 SPURS-P5V 2 SPURS-P5V
3 SPURS-P5V 4 SPURS-P5V
5 SPURS-P5V 6 SPURS-P5V
7 SPURS-P5V 8 SPURS-P5V
9 P1V 10 NC
11 P1V 12 GND
13 P1V 14 GND
15 P1V 16 GND
17 P1V 18 GND
19
P1V
20
GND
C.17 CN3010 MDC interface connector (12-pin)
Table C-17 MDC interface connector (12-pin)
Pin No. Signal Name Pin No. Signal Name
1 GND 2 NC
3 AZSDO1-P3P 4 NC
5 GND 6 E3V
7 AZSYC1-P3P 8 GND
9 AZSDI1-E3P 10 GND
11 AZRST1-E3N 12 XAZBC1-P3P
1T GND 2T GND
3T GND 4T GND
5T
GND
6T
GND
