Appendix C Pin Assignments Appendices
Qosmio G50 Maintenance Manual (960-683) [CONFIDENTIAL] C-41
C.61 CN7901 POWER connector (20-pin)
Table C-61 POWER connector (20-pin)
Pin No. Signal Name Pin No. Signal Name
1 P5V 2 P5V
3 P5V 4 P5V
5 P5V 6 P5V
7 P5V 8 P5V
9 P1V 10 NC
11 P1V 12 GND
13 P1V 14 GND
15 P1V 16 GND
17 P1V 18 GND
19 P1V 20 GND
1T GND 2T GND
