Toshiba QOSMIO G50 Maintenance Manual

Appendices Appendix C Pin Assignments
C-32 [CONFIDENTIAL] Qosmio G50 Maintenance Manual (960-683)
C.47 IS2140 MEDIA BRIDGE interface connector (46-pin)
Table C-47 MEDIA BRIDGE interface connector (46-pin)
Pin No. Signal Name Pin No. Signal Name
1 SDCD-P3N 2 GND
3
SDDAT1-P3P
4
SDDAT0-P3P
5
NC
6
GND
7
GND
8
SDCLK-P3P
9
GND
10
SDCMD-P3P
11
SDDAT1-P3P
12
SDDAT0-P3P
13
SADAT2-P3P
14
SDCD-P3N
15
SADAT3-P3P
16
SDCLK-P3P
17
P3V
18
GND
19
P3V
20
GND
21
NC
22
SDCMD-P3P
23
NC
24
SDDAT3-P3P
25
SDDAT2-P3P
26
GND
27
GND
28
SDCD-P3N
29
SDWP-P3P
30
SDWP-P3P
31
SMCE-P3N
32
SMCLE-P3P
33
SMALE-P3P
34
SDCMD-P3P
35
SMWP-P3N
36
GND
37
SDDAT0-P3P
38
SDDAT1-P3P
39
SDDAT2-P3P
40
SDDAT3-P3P
41
SMDAT4-P3P
42
SMDAT5-P3P
43
SMDAT6-P3P
44
SMDAT7-P3P
45
P3V
46
SDWP-P3P
