C.13 CN2710 RF interface connector (3-pin)
Table C-13 RF interface connector (3-pin)
Pin No. Signal Name Pin No. Signal Name
1 CN2711-1pin 2 GND
3
GND
C.14 CN2711 RF interface connector (3-pin)
Table C-14 RF interface connector (3-pin)
Pin No. Signal Name Pin No. Signal Name
1 CN2710-1pin 2 GND
3
GND
