Toshiba QOSMIO G50 Maintenance Manual

Appendix C Pin Assignments Appendices
Qosmio G50 Maintenance Manual (960-683) [CONFIDENTIAL] C-23
C.30 CN5320 RGB interface connector (15-pin)
Table C-30 RGB interface connector (15-pin)
Pin No. Signal Name Pin No. Signal Name
1 RED-PXP 2 GREEN-PXP
3 BLUE-PXP 4
NC
5
GND
6
GND
7
GND
8
GND
9
P5V
10
GND
11
NC
12
CRTSDA-P5P
13
HSYNC-P3P
14
VSYNC-P3P
15
CRTSCL-P5P
1T
GND
2T
GND
C.31 CN5350 HDMI interface connector (19-pin)
Table C-31 HDMI interface connector (19-pin)
Pin No. Signal Name Pin No. Signal Name
1 ZHDMT2-PYN 2 GND
3 ZHDMT2-PYN 4
ZHDMT1-PYP
5
GND
6
ZHDMT1-PYN
7
ZHDMT0-PYP
8
GND
9
ZHDMT0-PYN
10
ZHDMCK-PYP
11
GND
12
ZHDMCK-PYN
13
CECIN-S3N
14
NC
15
S5V
16
S5V
17
GND
18
S5V
19
HPDET1-S3P
1T
GND
2T
GND
3T
GND
4T
GND
