Toshiba QOSMIO G50 Maintenance Manual

Appendix C Pin Assignments Appendices
Qosmio G50 Maintenance Manual (960-683) [CONFIDENTIAL] C-11
C.8 CN2440 BCAS interface connector (8-pin) :Japanese
model Only
Table C-8 BCAS interface connector (8-pin)
Pin No. Signal Name Pin No. Signal Name
1
P5V
2
BCIO-P5P
3
BCRST-P5N
4
GND
5
XBCCLK-P5P
6
GND
7
BCCDET-P3N
8
GND
1T
GND
2T
GND
C.9 CN2520 EXPRESS CARD interface connector (26-pin)
Table C-9 EXPRESS CARD interface connector (26-pin)
Pin No. Signal Name Pin No. Signal Name
1
GND
2
ZUSBP1-E3N
3
ZUSBP1-E3P
4
CPUSB-E3N
5
NC
6
NC
7
E3V
8
E3V
9
P1V
10
P1V
11
PEWAKE-E3N
12
E3V
13
CRDRST-E3N
14
P3V
15
P3V
16
CRDCRQ-E3N
17
CPPE-E3N
18
XPECRD-PON
19
XPECRD-P0P
20
GND
21
ZERCRD-P1N
22
ZERCRD-P1P
23
GND
24
ZETCRD-P1N
25
ZETCRD-P1P
26
GND
