Toshiba QOSMIO G50 Maintenance Manual

Appendices Appendix C Pin Assignments
C-42 [CONFIDENTIAL] Qosmio G50 Maintenance Manual (960-683)
B-CAS board (FTUBC*):Japanese model Only
C.62 CN2451 BCAS interface connector (10-pin)
Table C-62 BCAS interface connector (10-pin)
Pin No. Signal Name Pin No. Signal Name
1
P5V
2
BCRST-P5N
3 XBCCLK-P5P 4 NC
5 GND 6 NC
7 BCIO-P5P 8 NC
9 GND 10 BCCDET-P3N
