Appendices Appendix C Pin Assignments
C-28 [CONFIDENTIAL] Qosmio G50 Maintenance Manual (960-683)
C.35 CN8771 CPU FAN interface connector (4-pin)
Table C-35 CPU FAN interface connector (4-pin)
Pin No. Signal Name Pin No. Signal Name
1 P5V 2 FANG1-P3P
3
GND
4
FPWMCPU-S3P
C.36 CN8781 VGA FAN interface connector (4-pin)
Table C-36 CPU FAN interface connector (4-pin)
Pin No. Signal Name Pin No. Signal Name
1 P5V 2 FANG1-P3P
3
GND
4
FPWMVGA-S3P
C.37 CN8800 DC-IN connector (5-pin)
Table C-37 DC-IN connector (5-pin)
Pin No. Signal Name Pin No. Signal Name
1 19V 2 19V
3
NC
4
GND
5
GND
1T
GND
2T
GND
C.38 CN8810 Battery connector (10-pin)
Table C-38 Battery connector (10-pin)
Pin No. Signal Name Pin No. Signal Name
1 F8810-2pin 2 BTMP1
3
Q8811-4pin
4
M5V
5
PSCL-S5P
6
PSDA-S5P
7
GND
8
DBT1OV-S5N
9
GND
10
GND
