CNT-SVP01C-EN 49
Chapter 4
Using the Schedule
application
The Tracer MP580/581 plug-in includes a schedule application that you
can use to set up a local schedule. The local schedule functions only when
a non-portable operator display is connected the controller. The local
schedule is used only if Tracer Summit is not communicating on the link.
Use the information in this chapter to set up the local daily schedule and
exceptions for the Tracer MP580/581 controller.
Viewing the status of the time-of-day
schedule
To view the status of the time-of-day schedule:
X In the Active Device View, click the Application tab. The status of the
Tracer MP580/581 applications appears. The current mode of the
schedule and the current day and time of the controller appear under
Schedule (Figure 34).
Figure 34. Time of day schedule status
