Make sure the controller is in run mode.
For information about how to exit to run
mode, see section 10.4 Run mode > Exit to
run mode.
To register the interface to a controller:
1. Press and hold the OK button on the controller
until one of the channel LEDs starts flashing.
2. Use buttons < or > to move the pointer to the
power LED (LED flashes red).
3. Press the OK button to enter system device
registration mode (power LED). The power LED
starts flashing according to the pattern long blink,
short pause, long blink. Channel 1 starts flashing
red.
4. Press the OK button to select Channel 1. The
channel LED starts flashing green.
5. USING THE INTERFACE START GUIDE:
5.1 Follow the instructions in section 8.5 Startup
guide until the button Link Touch Screen to
controller appears.
5.2 Press Link Touch Screen to controller to
initialize registration.
USING THE INTERFACE MENU SYSTEM:
5.1 Go to the Link menu (Main menu >
Preferences).
5.2 Press Link Touch Screen to controller to
initialize registration.
6. The interface gets registered to the controller.
The selected channel LED in the controller turns
fixed green and the registration is complete.
7. Press and hold the OK button on the controller
until the green LEDs turn off to end registration and
return to run mode.
To unregister an already registered interface, see section
10.6 Unregister channels in controller.
