9-14 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Parts List
Parts List 2.2 Feeder (2/3)
Item Parts name Part Number
1 Feed Assy (with 2-7) (Feed Roller Assembly)
2 CAM R (Right Feed Roller Cam) 008E 97492
3Roll Core
4 Roll Assy Feed (Feed Roller) 059K 66781
5Holder Feed
6Feed Shaft
7 CAM L (Left Feed Roller Cam) 008E 97481
8Holder BTM R
9 Plate Assembly Bottom (With 27-28) (Bottom Plate)
10 Holder BTM L
11 Holder Assy Separator (With 29-31) (Separator Pad
Assembly)
019K 11790
12 Spring Separator (Separator Spring) 809E 91661
13 Follower R (Right Follower) 008E 97512
14 Follower L (Left Follower) 008E 97502
15 —
16 —
17 Arm L (Left Follower Arm) 031E 98380
18 Spring NF (NF Spring) 809E 91680
19 —
20 Spring ACT REGI (No Paper Spring Actuator) 809E 91650
21 Actuator No Paper (No Paper Actuator) 120E 32601
22 Cover No Paper (No Paper Cover) (Phaser 6010N and
WorkCentre 6015 MFPs only)
848E 50650
23 Sensor Photo (No Paper Sensor) (Phaser 6010N and
WorkCentre 6015 MFPs only)
930W 00123
24 Arm R (Right Follower Arm) 031E 98390
25 Harness Assembly RKN SNS (J12-J120,J121,J122)
(Phaser 6010N and WorkCentre 6015 MFPs only)
26 Harness Assembly RK SNS (J12-J120,J122) (6000B
only)
27 Plate Bottom
28 Pad Main Paper Tray
29 Clutch Assy Friction
30 Roll Assy Separator
31 Holder Separator
To Next Page
