Xerox Phaser 6000 Service Manual

Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 10-31
Wiring
WorkCentre 6015 MFP Fuser
MCU Board
PL7.2.2
P/J26
P/J18
2
1
SG
4
3
3
2
1
STS
1
3
N HEAT1
LINE
SG
STS 2
FUSER EXIT SENSED (L) +3.3VDC
SG
PULL UP +3.3VDC
Fuser
PL5.1.1
LVPS
PL8.2.1
s6015-056
Thermostat
Heater
P/J201
STS 1
STS 2
1
2
3
Exit
Sensor
+3.3VDC
