9-24 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Parts List
Parts List 4.1 Toner Dispense
Item Parts name Part Number
1 Dispenser Assy (With 2-11)
2 Harness Assembly DCKR (J13-toner CRUM Y,M,C,K)
3Key-HW K
4Key HW YMC
5Frame Disp
6 Gear Idler 23 (Idler 23 Gear) 807E 32140
7 Clutch Assembly Oneway (Oneway Clutch
Assembly)
005K 10070
8 Conductor GND MOT
9 Motor Assy Disp (Toner Motor) 127K 61370
10 Frame Motor
11 Gear Idler 34 (Idler 34 Gear) 807E 32130
12 Cover Connector (Connector Cover) 848E 51070
13 —
14 —
15 —
16 —
17 Cleaner Assy (Cleaner Assembly) 042K 94280
18 Harness Assembly FSR Test (J206-J208)
19 Harness Assembly Dispense MOT (J20-J200, J201)
To Next Page
