10-20 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Wiring
20 3 H-133 Connects MCU Board and Harness Assembly
Dispense MOT
21 3 I-134 Connects MCU Board and Harness Assembly HVPS
22 3 J-134 Connects MCU Board and Image Processor Harness
23 3 I-133 Connects MCU Board and LED/MCU Cable
25 3 I-133 Connects MCU Board and Registration Clutch
26 3 I-134 Connects MCU Board and Fuser
101 2 G-127 Connects Fax Board and Image Processor Board
120 2 E-128 Connects Registration Sensor and Harness Assembly
RKN SNS
121 2 F-128 Connects No Paper Sensor and Harness Assembly
RKN SNS
122 2 H-127 K Mode Switching Sensor and Harness Assembly RKN
SNS
130 1 I-107 Connects Toner CRUM (K) and DCKR Harness
131 1 I-108 Connects Toner CRUM (C) and DCKR Harness
132 1 H-108 Connects Toner CRUM (M) and DCKR Harness
133 1 G-108 Connects Toner CRUM (Y) and DCKR Harness
140 2 C-126 Connects Mark On Belt Sensor and ADC1 TRO
Harness
141 2 E-126 Connects ADC Sensor and ADC1 TRO Harness
160 2 H-127 Connect Main Drive Assembly and Main MOT
Harness
200 1 H-111 Connects Toner Motor (CK) and Dispense MOT
Harness
201 1 G-111 Connects Toner Motor (YM) and Dispense MOT
Harness
201 3 C-140 Connects LVPS and Fuser
202 3 E-139 Connects LVPS and LVES Harness
204 3 F-139 Connects LVPS and Interlock Switch
205 3 E-140 Connects LVPS and Fan
206 3 E-139 Connects LVPS and FSR Test Harness
210 3 f-140 Connects HVPS and HVPS Harness
WorkCentre 6015 MFP Plug and Jack Designators (Continued)
P/J Map Coordinates Remarks
