Chapter 2
Board Setup and Configuration
Board Component Location
Figure 2-1 shows the VCU118 board component locations. Each numbered component
shown in the figure is keyed to Table 2-1. Table 2-1 identifies the components, references
the respective schematic page numbers, and links to a detailed functional description of the
components and board features in Chapter 3.
IMPORTANT: Figure 2-1 is for visual reference only and might not reflect the current revision of the
board.
CAUTION! The VCU118 board can be damaged by electrostatic discharge (ESD). Follow standard ESD
prevention measures when handling the board.
