Chapter 3: Board Component Descriptions
The connections between the BPI flash memory and the FPGA are listed in Table 3-4.
Table 3-5: BPI Flash Memory Connections to FPGA U1
FPGA (U1) Pin Net Name I/O Standard
U58 BPI Flash Memory
Pin # Pin Name
AP11 BPI_FLASH_D0 (NA BANK0) F2 DQ0
AN11 BPI_FLASH_D1 (NA BANK0) E2 DQ1
AM11 BPI_FLASH_D2 (NA BANK0) G3 DQ2
AL11 BPI_FLASH_D3 (NA BANK0) E4 DQ3
AM19 BPI_FLASH_D4 LVCMOS18 E5 DQ4
AM18 BPI_FLASH_D5 LVCMOS18 G5 DQ5
AN20 BPI_FLASH_D6 LVCMOS18 G6 DQ6
AP20 BPI_FLASH_D7 LVCMOS18 H7 DQ7
AN19 BPI_FLASH_D8 LVCMOS18 E1 DQ8
AN18 BPI_FLASH_D9 LVCMOS18 E3 DQ9
AR18 BPI_FLASH_D10 LVCMOS18 F3 DQ10
AR17 BPI_FLASH_D11 LVCMOS18 F4 DQ11
AT20 BPI_FLASH_D12 LVCMOS18 F5 DQ12
AT19 BPI_FLASH_D13 LVCMOS18 H5 DQ13
AT17 BPI_FLASH_D14 LVCMOS18 G7 DQ14
AU17 BPI_FLASH_D15 LVCMOS18 E7 DQ15
AR20 BPI_FLASH_A0 LVCMOS18 A1 A0
AR19 BPI_FLASH_A1 LVCMOS18 B1 A1
AV20 BPI_FLASH_A2 LVCMOS18 C1 A2
AW20 BPI_FLASH_A3 LVCMOS18 D1 A3
AU19 BPI_FLASH_A4 LVCMOS18 D2 A4
AU18 BPI_FLASH_A5 LVCMOS18 A2 A5
AV19 BPI_FLASH_A6 LVCMOS18 C2 A6
AV18 BPI_FLASH_A7 LVCMOS18 A3 A7
AW18 BPI_FLASH_A8 LVCMOS18 B3 A8
AY18 BPI_FLASH_A9 LVCMOS18 C3 A9
AY19 BPI_FLASH_A10 LVCMOS18 D3 A10
BA19 BPI_FLASH_A11 LVCMOS18 C4 A11
BA17 BPI_FLASH_A12 LVCMOS18 A5 A12
BB17 BPI_FLASH_A13 LVCMOS18 B5 A13
BB19 BPI_FLASH_A14 LVCMOS18 C5 A14
BC19 BPI_FLASH_A15 LVCMOS18 D7 A15
