Xilinx VCU118 User Manual

VCU118 Board User Guide 54
UG1224 (v1.0) December 15, 2016
www.xilinx.com
Chapter 3: Board Component Descriptions
Table 3-8 through Table 3-13 list the VCU118 FPGA U1 GTY transceiver bank 120, 122, 123,
125, 126, 127 connections, respectively.
Table 3-8: VCU118 FPGA U1 GTY Transceiver Bank 120 Connections
MGT
Bank
FPGA
(U1)
Pin
FPGA (U1) Pin
Name
Schematic Net Name
Connected
Pin
Connected Pin
Name
Connected
Device
GTY
Bank
120
BD42 MGTYTXP0_120 FMCP_HSPC_DP20_C2M_P Z8 DP20_C2M_P
FMC+ HSPC J22
BD43 MGTYTXN0_120 FMCP_HSPC_DP20_C2M_N Z9 DP20_C2M_N
BC45 MGTYRXP0_120 FMCP_HSPC_DP20_M2C_P M14 DP20_M2C_P
BC46 MGTYRXN0_120 FMCP_HSPC_DP20_M2C_N M15 DP20_M2C_N
BB42 MGTYTXP1_120 FMCP_HSPC_DP21_C2M_P Y6 DP21_C2M_P
BB43 MGTYTXN1_120 FMCP_HSPC_DP21_C2M_N Y7 DP21_C2M_N
BA45 MGTYRXP1_120 FMCP_HSPC_DP21_M2C_P M10 DP21_M2C_P
BA46 MGTYRXN1_120 FMCP_HSPC_DP21_M2C_N M11 DP21_M2C_N
AY42 MGTYTXP2_120 FMCP_HSPC_DP22_C2M_P Z4 DP22_C2M_P
AY43 MGTYTXN2_120 FMCP_HSPC_DP22_C2M_N Z5 DP22_C2M_N
AW45 MGTYRXP2_120 FMCP_HSPC_DP22_M2C_P M6 DP22_M2C_P
AW46 MGTYRXN2_120 FMCP_HSPC_DP22_M2C_N M7 DP22_M2C_N
AV42 MGTYTXP3_120 FMCP_HSPC_DP23_C2M_P Y2 DP23_C2M_P
AV43 MGTYTXN3_120 FMCP_HSPC_DP23_C2M_N Y3 DP23_C2M_N
AU45 MGTYRXP3_120 FMCP_HSPC_DP23_M2C_P M2 DP23_M2C_P
AU46 MGTYRXN3_120 FMCP_HSPC_DP23_M2C_N M3 DP23_M2C_N
AN40 MGTREFCLK0P_120 FMCP_HSPC_GBTCLK5_M2C_P Z20 GBTCLK5_M2C_P
AN41 MGTREFCLK0N_120 FMCP_HSPC_GBTCLK5_M2C_N Z21 GBTCLK5_M2C_N
AM38 MGTREFCLK1P_120 FMCP_HSPC_GBT1_5_P 19 Q5_P
U39 ICS855S006I
clock buffer
AM39 MGTREFCLK1N_120 FMCP_HSPC_GBT1_5_N 20 Q5_N
