Yealink VCM34 Administrator's Guide

| Configuring Call Settings | 209
Procedure
1. Do one of the following:
• On your web user interface, go to Setting > Call Features > Outbound Call Settings.
• On your VCS, go to More > Settings > Basic > Call Features.
For VP59, tap > Settings > Basic > Call Features.
On your CTP20/CTP18, tap > Settings > Basic > Cal Features.
2. Configure and save the following settings:
Parameter Description Configuration Method
Call Protocol/Call Type
Specify the desired call protocol
for placing calls.
The supported types are as
follows:
• Auto—the system
automatically uses the
available call protocol. The
system preferentially uses the
H.323 protocol to place calls.
• SIP—the system only uses
the SIP protocol for placing
calls.
• H.323—the system only uses
H.323 protocol for placing
calls.
Default: Auto.
Web user interface
Endpoint
CTP20/CTP18
Specifying the Video Call Rate
You can specify the maximum video call rate. The configurable video call rates on the system are: 64kb/s,
128kb/s, 256kb/s, 384kb/s, 512kb/s, 768kb/s, 1024kb/s, 1280kb/s, 1500kb/s, 2000kb/s, 3000kb/s, 4000kb/
s, 5000kb/s, 6000kb/s.
About this task
Note: The call rate of audio and PC content are also affected by this configuration.
Procedure
1. Do one of the following:
• On your web user interface, go to Setting > Call Features > Outbound Call Settings.
• On your VCS, go to More > Settings > Basic > Call Features.
For VP59, tap > Settings > Basic > Call Features.
On your CTP20/CTP18, tap > Settings > Basic > Cal Features.

Yealink VCM34 Specifications

General

Product type	Microphone
Product color	Black, Grey
LED indicators	Yes
Package depth	196 mm
Package width	310 mm
Package height	80 mm
Package weight	4260 g
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	2
Power source type	PoE
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 90 %
Quantity	1
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	171.5 mm
Width	169 mm
Height	37.5 mm
