Yealink VCM34 Administrator's Guide

| Getting Started | 41
CP900/CP700 Ultra-Compact Speakerphone
After you connect CP900/CP700 to VP59 via a USB cable, VP59 will automatically take CP900/CP700 as
audio input or output device. You can use CP900/CP700 to control the call on VP59, adjust the volume,
and set the mute status.
Name Description
1 Microphone Provide optimal voice pickup performance.
2 Bluetooth Button Enable/disable the Bluetooth. Tap it for 2 seconds
to enable the pairing mode, then CP900/CP700 can
search for and connect to a device. Double-tap to
disconnect. Tap again to reconnect.
3 Volume Down Tap to turn down the volume.
Note: If you do not use the handset and
headset, the volume of CP900/CP700 is
synchronized with the one of VP59.
4 Answer Call Answer the call; tap it for 6 seconds to reset CP900/
CP700 to factory.
5 Power On/Off Power on/off CP900/CP700.
6 Mute Key Mute/unmute the microphone.
Note: If you do not use the handset and
headset, the mute status of CP900/CP700 is
synchronized with the one of VP59.
7 Volume Up Tap to turn up the volume.
Note: If you do not use the handset and
headset, the volume of CP900/CP700 is
synchronized with the one of VP59.
8 End Call Hand up the call or reject an incoming call; tap it for 6
seconds to reset CP900/CP700 to factory.
8 Voice Assistant Button Enable the voice assistant.

Yealink VCM34 Specifications

General

Product type	Microphone
Product color	Black, Grey
LED indicators	Yes
Package depth	196 mm
Package width	310 mm
Package height	80 mm
Package weight	4260 g
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	2
Power source type	PoE
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 90 %
Quantity	1
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	171.5 mm
Width	169 mm
Height	37.5 mm
