| Getting Started | 23
Port Name Description
2 VC Hub/Phone
• If you want to use wired sharing to present, connect this port to
the Codec port on the VCH50 video conferencing hub/to the PoE
port on the VCH51 video conferencing hub.
• Connect to CTP20.
• If you need an audio device, connect this port to the Internet port
on the CP960 Conference phone.
• Connect to VCM38/VCM38.
3 DC48V Connect to the power source via a power adapter.
4 HDMI Connect to a monitor for displaying video images.
5 Internet Connect to the network device.
6 Reset Key Reset the VCS endpoint to factory defaults.
7 Security Slot Allow you to connect a universal security cable to the VCS endpoint,
so you can lock the VCS endpoint down. The VCS endpoint cannot
be removed when locked.
Hardware of VC200/VC200-E
VC200/VC200-E is an entry-level smart video conferencing endpoint designed for small and huddle room.
Supporting 16:9 and 4:3 aspect ratios, it is compatible with different audio devices, and can adapt to the
monitors automatically. VC200/VC200-0 possesses many features, ultra HD 4K, 4 x digital zoom camera,
103° super-wide angle lens, white balance automatic gain and others. With 6 beamforming microphone
arrays for direct voice pickup and Yealink Noise Proof Technology, VC200 brings excellent audio effect in
small rooms and ensures that everyone can be heard clearly.
• Front Panel of VC200/PVT950 Codec
• Rear Panel of VC200/VC200-E
• Bottom Panel of VC200/VC200-E
Front Panel of VC200/PVT950 Codec
The LED indicator on the camera indicates different camera status.
Related information
LED Indicators of the VCS Devices
