Yealink VCM34 Administrator's Guide

| System Maintenance | 262
Exporting the Log Files to a USB Flash Drive
Procedure
1. On your web user interface, go to Setting > Configuration > Local Log.
2. In the Enable Local Log field, select On.
3. In the USB Auto Exporting Syslog field, select On.
4. Click Confirm.
A folder named yealink.debug appears in your USB flash drive, which includes the log files.
Note:
The severity level of the exported Module Log will not be greater than the local Log Level. For
example: If you set Local Log Level to 3 and set Talk log Level to 6, the exported Talk log Level
will still be 3 in your exported local log. If you set Local Log Level to 5 and set Talk log Level to 4,
the exported Talk log Level will be 4 in your exported local log.
Exporting the Log Files to a Syslog Server
Procedure
1. On your web user interface, go to SettingConfigurationSyslog.
2. Configure and save the following settings:
Parameter Description Configuration Method
Enable Syslog
Select On to enable the system
to upload log messages to the
syslog server.
Default: On.
Web user interface
Syslog Server Configure the IP address or
the domain name of the syslog
server.
Web user interface
Port Configure the port of the syslog
server.
Web user interface
Syslog Transport Type
Configure the transport protocol
that the device uses when
exporting log messages to the
syslog server.
• UDP
• TCP
• TLS
Default: UDP.
Web user interface

Yealink VCM34 Specifications

General

Product type	Microphone
Product color	Black, Grey
LED indicators	Yes
Package depth	196 mm
Package width	310 mm
Package height	80 mm
Package weight	4260 g
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	2
Power source type	PoE
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 90 %
Quantity	1
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	171.5 mm
Width	169 mm
Height	37.5 mm
