15 / 184
Technical specification
Item Specification
Size
Length 2010mm(79.1 in)
Width 770mm(30.3 in)
Height 1350mm(53.2 in)
Wheel base 1390mm(54.7 in)
Body bike
Complete vehicle dry mass 158kg(348.3 lbs)
Gross mass 168 kg(370.4 lbs)
Minimum ground clearance 155 mm(6.1 in)
Gasoline tank volume 12L(3.17 US gal, 2.64 lmp gal)
Seat height 760mm(29.9 in)
Form of frame Steel pipe frame
Tire structure Semi-slick tires
Front tire specification 110/80－14 CM－SC01 59S
Rear tire specification 140/70－14 CM－SC01 68S
Front rim specification MT:2.5×14
Rear rim specification MT:3.75×14
Brake fluid DOT4
Brake system Dual channel ABS
Oil consumption
Replace fine filter：
1.75L（0.46 US gal,0.39 lmp
gal）
Without replacing the fine filter：
1.7L（0.45 US gal,0.37 lmp gal）
Gearbox oil consumption 0.2L（0.05 US gal,0.04 lmp gal）
Engine
Body Aluminum alloy
Total number of cylinders Single cylinder
Camshaft method Single overhead camshaft (SOHC)
Bore X stroke 72×76mm(2.83×2.99 in)
cooling method Water cooling
Fuel oil 95 and above
Compression ratio 11.8 : 1
Displacement 309cm3(18.8 cu-in)
Fuel supply method EFI
EFI system brand BOSCH
Idle speed (r/min) 1600±100
Maximum power (kW/rpm) 24.5 / 7500
Maximum torque 32N.m(3.3 kgf.m,24 lbf.ft) / 5500 rpm
Transmission type Automatic stepless speed change
Throttle valve body 35mm(1.4 in)
Spark plug
Spark plug model NGK LMAR8A－9
Gap 0.8～0.9mm(0.031～0.035 in)
Resistance (kΩ) 3～7.5
