box.
Disassembly the front storage box
panel
a. Remove the two non-standard M6x16 bolts⑸ from
the front storage box panel with the 5# inner hexagon,
and remove the bushing⑵ and buffer glue⑶.
b. Find out the the 3 connectors on the left side of
storage box panel and unplug them on the next to the
tap lock
c. Find out and unplug the PKE bullet connector, PKE
connector, and PKE antenna connector on the right side
of the front storage box panel.
d. Remove the front storage box panel.
