161 / 184
c. Put the rubber pad ⒀ on the direction column
adjustment nut; then screw in the second direction
column adjustment nut ⑿, screw the second direction
column adjustment nut ⑿ to align with the notch of the
first direction column adjustment nut ⑿, put Insert the
snap-in gasket ⒁; finally screw in the third steering
column adjusting nut ⑿, torque: 100N.m (10.2 kgf.m, 74
bf.ft)
d. Install the semi-circular key in the groove of the lower
link plate, then align the gap between the spacer and the
base ⒃ with the semi-circular key ⒂, and finally screw
in the cap nut ⒄, torque: 100N.m (10.2 kgf.m, 74 bf.ft)
6. Install other disassembly components
a. Refer to "Replace the front shock absorber" to
replace the front shock absorber.
b. Refer to "Replace the front wheel" to reinstall the
front wheel assembly.
c. Refer to "Replace the direction handle" to install the
assembly back in the direction.
●The vehicle must be parked on a level and stable
ground or on a lifting platform.
