ABB ACS355 series User Manual

Actual signals and parameters 201
DI1,2,3(INV) Constant speed selection through inverted digital inputs DI1,
DI2 and DI3. 1 = DI active, 0 = DI inactive.
-12
DI3,4,5(INV) See selection DI1,2,3(INV).-13
1202 CONST
SPEED 1
Defines constant speed (or drive output frequency) 1. E: 5.0 Hz
U: 6.0 Hz
0.0…599.0 Hz /
0…30000 rpm
Speed in rpm. Output frequency in Hz if parameter 9904
MOTOR CTRL MODE setting is SCALAR: FREQ.
1 = 0.1 Hz
/ 1 rpm
1203 CONST
SPEED 2
Defines constant speed (or drive output frequency) 2. E: 10.0 Hz
U: 12.0 Hz
0.0…599.0 Hz /
0…30000 rpm
Speed in rpm. Output frequency in Hz if parameter 9904
MOTOR CTRL MODE setting is SCALAR: FREQ.
1 = 0.1 Hz
/ 1 rpm
1204 CONST
SPEED 3
Defines constant speed (or drive output frequency) 3. E: 15.0 Hz
U: 18.0 Hz
0.0…599.0 Hz /
0…30000 rpm
Speed in rpm. Output frequency in Hz if parameter 9904
MOTOR CTRL MODE setting is SCALAR: FREQ.
1 = 0.1 Hz
/ 1 rpm
1205 CONST
SPEED 4
Defines constant speed (or drive output frequency) 4. E: 20.0 Hz
U: 24.0 Hz
0.0…599.0 Hz /
0…30000 rpm
Speed in rpm. Output frequency in Hz if parameter 9904
MOTOR CTRL MODE setting is SCALAR: FREQ.
1 = 0.1 Hz
/ 1 rpm
1206 CONST
SPEED 5
Defines constant speed (or drive output frequency) 5. E: 25.0 Hz
U: 30.0 Hz
0.0…599.0 Hz /
0…30000 rpm
Speed in rpm. Output frequency in Hz if parameter 9904
MOTOR CTRL MODE setting is SCALAR: FREQ.
1 = 0.1 Hz
/ 1 rpm
1207 CONST
SPEED 6
Defines constant speed (or drive output frequency) 6. E: 40.0 Hz
U: 48.0 Hz
0.0…599.0 Hz /
0…30000 rpm
Speed in rpm. Output frequency in Hz if parameter 9904
MOTOR CTRL MODE setting is SCALAR: FREQ. Constant
speed 6 is used also as jogging speed. See section Control
of a mechanical brake on page 159.
1 = 0.1 Hz
/ 1 rpm
All parameters
No. Name/Value Description Def/FbEq
DI DI2 DI3 Operation
1 1 1 No constant speed
0 1 1 Speed defined by par. 1202 CONST SPEED 1
1 0 1 Speed defined by par. 1203 CONST SPEED 2
0 0 1 Speed defined by par. 1204 CONST SPEED 3
1 1 0 Speed defined by par. 1205 CONST SPEED 4
0 1 0 Speed defined by par. 1206 CONST SPEED 5
1 0 0 Speed defined by par. 1207 CONST SPEED 6
0 0 0 Speed defined by par. 1208 CONST SPEED 7
