ABB ACS355 series User Manual

214 Actual signals and parameters
DI2 See selection DI1.2
DI3 See selection DI1.3
DI4 See selection DI1.4
DI5 See selection DI1.5
COMM Fieldbus interface as the source for the inverted Start
enable (Start disable) signal, ie, Control word 0302 FB CMD
WORD 2 bit 18 (bit 19 for Start enable 2). The Control word
is sent by the fieldbus controller through the fieldbus
adapter or embedded fieldbus (Modbus) to the drive. For
the Control word bits, see section DCU communication
profile on page 333.
Note: This setting applies only for the DCU profile.
7
DI1(INV) External signal required through inverted digital input DI1. 0
= Start enable. If Start enable signal is switched off, the
drive will not start or it coasts to stop if it is running and
alarm START ENABLE 1 MISSING (2021) is activated.
-1
DI2(INV) See selection DI1(INV).-2
DI3(INV) See selection DI1(INV).-3
DI4(INV) See selection DI1(INV).-4
DI5(INV) See selection DI1(INV).-5
1609 START
ENABLE 2
Selects the source for the Start enable 2 signal. See
parameter 1608 START ENABLE 1.
NOT SEL
See parameter 1608 START ENABLE 1.
1610 DISPLAY
ALARMS
Activates/deactivates alarms OVERCURRENT (2001),
OVERVOLTAGE (2002), PID SLEEP (2018) and DEVICE
OVERTEMP (2009). For more information, see chapter
Fault tracing on page 349.
NO
NO Alarms are inactive. 0
YES Alarms are active. 1
All parameters
No. Name/Value Description Def/FbEq

ABB ACS355 series Specifications

General

Power Range	0.37 to 22 kW
Protection Class	IP20
Output Frequency	0 to 500 Hz
Braking Chopper	Built-in
Control Method	Scalar control, Vector control
Ambient Temperature	-10 to +50 °C
Communication Protocols	Modbus, CANopen
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature
Cooling Method	Air-cooled
Number of Phases	3-phase
