ABB ACS355 series User Manual

Actual signals and parameters 221
DI3(INV) See selection DI1(INV).-3
DI4(INV) See selection DI1(INV).-4
DI5(INV) See selection DI1(INV).-5
UP Counts up 0
DI1 Counter direction selection through digital input DI1. 0 =
counts up, 1 = counts down.
1
DI2 See selection DI1.2
DI3 See selection DI1.3
DI4 See selection DI1.4
DI5 See selection DI1.5
DOWN Counts down 6
1911 CNTR S/S
COMMAND
Selects the source for the drive start/stop command when
parameter 1001 EXT1 COMMANDS value is set to
COUNTR START / COUNTER STOP.
NOT SEL
DI1(INV) Start/stop command through inverted digital input DI1.
When parameter 1001 EXT1 COMMANDS value is
COUNTER STOP: 0 = start. Stop when counter limit defined
by parameter 1905 COUNTER LIMIT has been exceeded.
When parameter 1001 value is COUNTR START: 0 = stop.
Start when counter limit defined by parameter 1905 has
been exceeded.
-1
DI2(INV) See selection DI1(INV).-2
DI3(INV) See selection DI1(INV).-3
DI4(INV) See selection DI1(INV).-4
DI5(INV) See selection DI1(INV).-5
NOT SEL Not start/stop command source 0
DI1 Start/stop command through digital input DI1.
When parameter 1001 EXT1 COMMANDS value is
COUNTER STOP: 1 = start. Stop when counter limit defined
by parameter 1905 COUNTER LIMIT has been exceeded.
When parameter 1001 value is COUNTR START: 1 = stop.
Start when counter limit defined by parameter 1905 has
been exceeded.
1
DI2 See selection DI1.2
DI3 See selection DI1
.3
DI4 See selection DI1.4
DI5 See selection DI1.5
ACTIVATE External start/stop command, eg, through fieldbus 6
All parameters
No. Name/Value Description Def/FbEq

ABB ACS355 series Specifications

General

Power Range	0.37 to 22 kW
Protection Class	IP20
Output Frequency	0 to 500 Hz
Braking Chopper	Built-in
Control Method	Scalar control, Vector control
Ambient Temperature	-10 to +50 °C
Communication Protocols	Modbus, CANopen
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature
Cooling Method	Air-cooled
Number of Phases	3-phase
