362 Fault tracing
0022 SUPPLY PHASE
(3130)
0306 bit 5
(programmable
fault function
3016)
Intermediate circuit DC
voltage is oscillating due
to missing input power
line phase or blown fuse.
Check input power line fuses and
installation.
Check for input power supply
imbalance.
Check the load.
Trip occurs when DC
voltage ripple exceeds
14% of nominal DC
voltage.
Check fault function parameter 2619
DC STABILIZER.
0023 ENCODER ERR
(7301)
0306 bit 6
(programmable
fault function
5003)
Communication fault
between pulse encoder
and pulse encoder
interface module or
between module and
drive.
Check pulse encoder and its wiring,
pulse encoder interface module and
its wiring and parameter group 50
ENCODER settings.
0024 OVERSPEED
(7310)
0306 bit 7
Motor is turning faster
than 120% of the highest
allowed speed due to
incorrectly set
minimum/maximum
speed, insufficient
braking torque or
changes in load when
using torque reference.
Operating range limits
are set by parameters
2001 MINIMUM SPEED
and 2002 MAXIMUM
SPEED (in vector
control) or 2007
MINIMUM FREQ and
2008 MAXIMUM FREQ
(in scalar control).
Check minimum/maximum frequency
settings (parameters 2001 MINIMUM
SPEED and 2002 MAXIMUM
SPEED).
Check adequacy of motor braking
torque.
Check applicability of torque control.
Check need for brake chopper and
resistor(s).
0027 CONFIG FILE
(630F)
0306 bit 10
Internal configuration file
error
Replace the drive.
0028 SERIAL 1 ERR
(7510)
0306 bit 11
(programmable
fault function
3018
, 3019)
Fieldbus communication
break
Check status of fieldbus
communication. See chapter Fieldbus
control with embedded fieldbus on
page 313, chapter Fieldbus control
with fieldbus adapter on page 339 or
appropriate fieldbus adapter manual.
Check fault function parameter 3018
COMM FAULT FUNC and 3019
COMM FAULT TIME settings.
Check connections and/or noise on
the line.
Check if master can communicate.
0029 EFB CON FILE
(6306)
0306 bit 12
Configuration file reading
error
Error in reading the configuration files
of the embedded fieldbus. See
fieldbus user’s manual.
CODE FAULT CAUSE WHAT TO DO

ABB ACS355 series Specifications

General

Power Range	0.37 to 22 kW
Protection Class	IP20
Output Frequency	0 to 500 Hz
Braking Chopper	Built-in
Control Method	Scalar control, Vector control
Ambient Temperature	-10 to +50 °C
Communication Protocols	Modbus, CANopen
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature
Cooling Method	Air-cooled
Number of Phases	3-phase
