ABB ACS380 User Manual

Transportation in the
protective package
Storage in the protect-
ive package
Operation installed
for stationary use
Requirement
--230 V drives:
0 … 2000 m
(0 … 6562 ft) above
sea level (with output
derating above 1000 m
[3281 ft])
Installation site alti-
tude
400/480 V drives:
0 … 4000 m
(0 … 13123 ft) above
sea level (with output
derating above 1000 m
[3281 ft])
See Output derat-
ing (page 131).
-40 … +70 °C ±2%-40 … +70 °C ±2%-10 … +60 °C
(14 … 140 °F). For
frame R0, -
10 … +50 °C
(14 … 122 °F).
Surrounding air tem-
perature (-40 … +158 °F ±2%)(-40 … +158 °F ±2%)
If the temperature is
more than 50 °C
(122 °F), output derat-
ing is necessary. See
Output derat-
ing (page 131).
No frost permitted.
Max. 95%Max. 95%5 … 95%Relative humidity
No condensation permitted. Maximum permitted relative humidity is 60%
in the presence of corrosive gases.
IEC 60721-3-2: 1997IEC 60721-3-1: 1997IEC 60721-3-3: 2002Contamination levels
(IEC 60721-3-x)
Class 2C2Class 1C2Class 3C2- Chemical gases
Class 2S2Class 1S3. (packing
must support this, other-
wise 1S2)
Class 3S2. No conduct-
ive dust permitted.
- Solid particles
--Pollution degree 2Pollution degree
(IEC/EN 61800-5-1)
156 Technical data

ABB ACS380 Specifications

General

Mounting	Wall-mounted
Enclosure Class	IP20
Built-in Features	Braking chopper
Communication	Modbus RTU
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit, ground fault
Operating Temperature	-10°C to +50°C
Storage Temperature	-40°C to +70°C
Humidity	5 to 95% relative humidity, non-condensing
Control Method	Scalar control, vector control
