ABB ACS380 - BTAC-02 Layout and Installation

￭ Layout
1. BTAC module
8
1
2
3
4
5
6
7
9
10
2. Locking screw hole
3. X103 connector
4. X104 connector
5. X105 connector
6. X106 connector
7. Internal X100 connector
8. Internal X102 connector
9. Grounding rail
10. Grounding screw
Mechanical installation
See the electrical installation instructions of the drive.
Electrical installation
￭ Wiring – General
Connect the pulse encoder to the BTAC module with cables as specified in this table.
206 BTAC-02 pulse encoder interface module
