Def /
FbEq16/32
DescriptionName/ValueNo.
0Output is not energized.Not energized
1Output is energized.Energized
…For the complete parameter list, refer to the drive firmware manual.
0.0 sDefines the activation delay for relay output RO5.RO5 ON delay15.11
10 = 1 sActivation delay for RO5.0.0 … 3000.0 s
0.0 sDefines the deactivation delay for relay output RO5.RO5 OFF delay15.12
10 = 1 sDeactivation delay for RO5.0.0 … 3000.0 s
Not
energized
Selects a drive signal to be connected to relay output
RO6.
RO6 source15.13
0Output is not energized.Not energized
1Output is energized.Energized
…For the complete parameter list, refer to the drive firmware manual.
0.0 sDefines the activation delay for relay output RO6.RO6 ON delay15.14
10 = 1 sActivation delay for RO6.0.0 … 3000.0 s
0.0 sDefines the deactivation delay for relay output RO6.RO6 OFF delay15.15
10 = 1 sDeactivation delay for RO6.0.0 … 3000.0 s
Not
energized
Selects a drive signal to be connected to relay output
RO7.
RO7 source15.16
0Output is not energized.Not energized
1Output is energized.Energized
…For the complete parameter list, refer to the drive firmware manual.
0.0 sSets the activation delay for relay output 7.RO7 ON delay15.17
10 = 1 sActivation delay for relay output 7.0.0…3000.0 s
0.0 sSets the deactivation delay for relay output 7.RO7 OFF delay15.18
10 = 1 sDeactivation delay for relay output 7.0.0…3000.0 s
Technical data
External connectors: Four 3-pin (1×3) spring-clamp type terminal blocks, tin plated,
2.5 mm
2
(14 AWG) wire size, pitch 5.0 mm.
Internal connectors: Connector X102 provides relay control signals from the control
board: 1×8 pin header, pitch 2.54 mm, height 33.53 mm. Connector X100 is not in use
in BREL-01: 2×4 pin header, pitch 2.54 mm, height 15.75 mm.
BREL-01 relay output extension module 225
