ALLEN & HEATH SQ-6 Reference Guide

 104
Reference Guide V1.5.0
17. Mix/System Reset
17.1 Reset Mix Settings
The SQ has multiple ‘Reset Mix Settings’. These are used to ‘zero the desk’ for
different uses.
This will clear the current state of the SQ, but does not affect stored Scene or Library
data, so save the current settings
Press the ‘Setup’ screen key, then touch the ‘Mixer Config’ tab followed by the ‘Role’
tab.
Select an operating role and information on default settings will be displayed. Touch
the ‘Reset’ button to reset the mix with these settings.
Global filters are ignored and safes are all switched off when mix settings are reset.
 The Master Fader Mode allows you to choose whether the master fader controls the
master send level of the selected mix, or the level of the listen bus. For more information
see the Mixer Role section.
roles
description of settings
master fader mode
reset

ALLEN & HEATH SQ-6 Specifications

General

Channels quantity	48 channels
Supported sample rates	96 kHz
Digital sound processing	- bit
DJ mixer	-
Product color	Black
Output impedance	75 Ω
MIDI out	Yes
RJ-45 ports quantity	1
Power consumption (typical)	- W

Weight and Dimensions

Depth	514.9 mm
Width	638 mm
Height	198 mm
Weight	14500 g
Package depth	680 mm
Package width	820 mm
Package height	360 mm
Package weight	17300 g
