ALLEN & HEATH SQ-6 Reference Guide

 109
Reference Guide V1.5.0
FX Send
or
L
PFL
PFL
FADER
L
From:
Ret to AUX/FX
FX SEND
R
FX RETURN x8
AFL
AFL
Send > Return FX
R
Strip METER
RackFX x8
Any MIX
Ret to MAIN
LEV
Post
FADER
in-place
Inserted FX
DCA
Input DIR OUT
Pre
Ret to GRP
PEQ
MUTE
MUTE
ASSIGN+PAN
METER
Pink Noise
OUTPUT SOCKET
MUTE
Bandpass Noise (Sweep)
Assign to: INPUT CH, GRP, AUX, MAIN, MTX
White Noise
Assign to: GRP, AUX, MAIN, MTX,
LEV
Sine (Sweep 20-20kHz)
HPF
TALKBACK
Press to TALK
SIG GEN
PAFL Meter
PFL/AFL MONITOR
DELAY
Listen L/R/M
+
PAFL L/R
POL
Linked
(AFL not affected)
PFL TRIM
0
TRIM
DELAY
+
-24dB
EXT IN
Meters RTA
Listen Level
0dB

ALLEN & HEATH SQ-6 Specifications

General

Channels quantity	48 channels
Supported sample rates	96 kHz
Digital sound processing	- bit
DJ mixer	-
Product color	Black
Output impedance	75 Ω
MIDI out	Yes
RJ-45 ports quantity	1
Power consumption (typical)	- W

Weight and Dimensions

Depth	514.9 mm
Width	638 mm
Height	198 mm
Weight	14500 g
Package depth	680 mm
Package width	820 mm
Package height	360 mm
Package weight	17300 g
