Possible SoftRotary assignments
Control Type
Control Option 1
Control Option 2
Key
Unassigned
N/A
N/A
N/A
AMM Priority
Current Selection, all input
channels
N/A
Unassigned, On
Compressor
Threshold, Ratio, Gain,
Attack, Release
Current Selection, all
input and mix channels
Unassigned, In
DCA Level Fader
DCA’s 1 to 8
N/A
Unassigned, Mute,
PAFL, Spill
FX Parameter
Time*, Amount*
Rack FX Slot (1-8)
Unassigned, Tap
Tempo, Mute Send,
Mute Return, Insert
In
Gate
Threshold, Depth, Attack,
Hold, Release
Current Selection, all
input channels
Unassigned, In
HPF Frequency
Current Selection, all input
channels
N/A
Unassigned, In
Main Level Fader
Current Selection, all main
send levels
N/A
Unassigned, Mute,
PAFL
MIDI absolute
MIDI Channel
CC#
Unassigned, Note
MIDI relative
MIDI Channel
CC#
Unassigned, Note
MIDI Program
Change
MIDI Channel
N/A
Sends MIDI
PAFL Listen Level
N/A
N/A
N/A
Pan
Current Selection, all input
and mix channels
Current Mix, all stereo
aux
Unassigned, Centre
PEQ Band
LF, LM, HM, HF
Current Selection, all
input and mix channels
Gain/Width/Freq
Preamp model
Fine Adjustment, Level
Current Selection, all
input channels
Unassigned, In
Preamp
Gain, Trim
Current Selection, all
input and mix channels
Unassigned, Pad,
Polarity
Send Level Fader
Current Selection, all input
and mix channels
Current Mix, Main LR, all
aux and FX sends
Unassigned, Assign
(to mix)
*FX Parameter ‘Time’ and ‘Amount’ functions for different FX units
FX Unit
Time
Amount
SMR Reverb
Decay Time
N/A
Gated Verb
N/A
N/A
Stereo Tap Delay
Delay Time (L - use ‘Link’ for R)
Feedback Amount
ADT
Delay Separation
Thickness
Blue Chorus
Rate
Depth
Symphonic Chorus
Frequency
Depth
Flanger
Speed
Depth
Phaser
Rate
Depth

ALLEN & HEATH SQ-6 Specifications

General

Channels quantity	48 channels
Supported sample rates	96 kHz
Digital sound processing	- bit
DJ mixer	-
Product color	Black
Output impedance	75 Ω
MIDI out	Yes
RJ-45 ports quantity	1
Power consumption (typical)	- W

Weight and Dimensions

Depth	514.9 mm
Width	638 mm
Height	198 mm
Weight	14500 g
Package depth	680 mm
Package width	820 mm
Package height	360 mm
Package weight	17300 g
