- Use the nut to move the base of the tool until you

can see end of the oil seal driving stroke

- Remove all of the tool components following the procedure in reverse order

CAUTION

FAILURE TO COMPLY WITH THIS ASSEMBLY PROCEDURE CAN SERIOUSLY DAMAGE THE

ENGINE DUE TO THE WRONG TENSIONING OF THE OIL PUMP CONTROL CHAIN.

Oil pump

Removal

- Remove the chain cover acting on the 3 retaining

screws as shown in the figure and the relevant

copper washer.

- Extract the cover using the appropriate appen-

dages.

NOTE

WITH THE AIM OF AVOIDING DAMAGING THE APPEN-

DAGES PRACTICE A RUN PARALLEL TO CRANKSHAFT.

- Remove the cover of the pump control pulley us-

ing the two retainers, as shown in the figure.

- Block the rotation of the oil pump control pulley

using a screwdriver inserted through one of its two

holes.

Engine SPORTCITY ONE 125

ENG - 114
