APRILIA SPORTCITY ONE 125 Service Station Manual

Front brake pump
Removal
•
Remove the front and rear handlebar covers.
•
Remove the brake pipes and the contacts of the stop light switch.
•
Undo the two screws «1».
To refit, carry out the removal operations but in reverse order and tighten the screws to the prescribed
torque.
ONCE REFITTING IS FINISHED, BLEED THE SYSTEM.
Locking torques (N*m)
Brake pump to handlebar fixing screw 8.05 Brake pipe to brake pump fixing screw 18
Rear drum brake
•
Remove the rear wheel.
•
Hold the lower shoe and slide it with the
upper one.
For fitting:
•
First assembly two shoes and the
springs then place them on the pin and
on the cam.
To replace the transmission:
•
Remove the front handlebar cover.
•
Loosen the brake set screw
•
Release the transmission from its
clamps to the engine and from its
clamps to the chassis.
•
Adjust the drum brake activation point.
Locking torques (N*m)
SPORTCITY ONE 125 Braking system
BRAK SYS - 155

APRILIA SPORTCITY ONE 125 Specifications

General

Engine Type	Single cylinder, 4-stroke
Displacement	124 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Front Suspension	Telescopic fork
Rear Suspension	Single shock absorber
Front Brake	Disc
Rear Brake	Drum
Front Tire	120/70 - 14
Rear Tire	120/70 - 14
Transmission	Automatic
Fuel Capacity	7 liters
