Cooling hood
-Remove the housing acting on the 4 retaining
screws.
CAUTION
DURING REMOVAL SLIDE THE HOUSING CONNECTOR
ON THE HOUSING.
- Loosen the clamp and remove the carburettor
from the manifold.
-Remove the complete manifold acting on the 2
retainers as shown in the figure.
- Remove the 2 self threading screws, left and right
and the lateral base retaining screw on the crank-
case base.
- Take off the housings.
- Remove the gasket seal of the housing on the
head.
NOTE
IF THE FLYWHEEL HOUSING IS NOT REMOVED, IT IS AL-
SO NECESSARY TO REMOVE THE TWO KNOB SCREWS.
On the vehicles equipped with the engines mentioned if they are losing a full circle at full gas, we suggest
to intervene on the vacuum socket inserting on the inlet manifold widening the hole from 0.4 mm to 1.5
mm. Remember that such operation must have performed on a disassembled manifold which must be
cleaned afterwards.
Cooling fan
- Remove the cooling fan by acting on the three
fixings indicated in the figure.
Engine SPORTCITY ONE 125
ENG - 82
