level indicators
CAUTION
THE CONTINUITY TEST SHOULD BE PERFORMED WITH THE RELATIVE CONNECTORS DIS-
CONNECTED.
•
Check continuity of the Green cable which connects the instrument panel to the 15A fuse
C.
•
Check continuity of the Grey-Green cable which connects the instrument panel to the probe
checking fuel level.
•
Measure resistance present between the Grey-Green cable and the Blue cable of the fuel
level probe by moving the arm with the float to different positions.
•
If the values measured are correct but the instrument panel value displayed is incorrect,
check wiring continuity.
Characteristic
Resistance value with empty tank
~ 101 Ω
Resistance value with full tank
~ 7.4 Ω
Lights list
BULBS AND WARNING LIGHTS
Specification
Desc./Quantity
1 Low-beam bulb 12 V - 35 W (Halogen) H8
2 High-beam bulb 12 V - 35 W (Halogen) H8
3 Tail light bulb 12V - 3W
4 Front turn indicator bulbs 12 V - 21 W (Halogen) H21W
5 Rear turn indicator bulbs 12V - 16W
6 Rear position light /stop light bulb 12V - 5/21W
7 License plate light bulb 12V - 5W
8 Instrument panel light bulbs 12V - 1.2W
9 Oil pressure warning light 12V - 1.2W
10 Turn indicator warning light 12V - 1.2W
11 High-beam warning light 12V - 1.2W
CAUTION
THE CONTINUITY TEST SHOULD BE PERFORMED WITH THE RELATIVE CONNECTORS DIS-
CONNECTED.
Check tail lights and panel lightning
•
Check that bulb operates properly.
•
Check continuity between the Green cable of 15A fuse C and the Yellow cables of the tail
lights bulbs.
•
Also check continuity of the Green cable of the instrument panel connector.
SPORTCITY ONE 125 Electrical system
ELE SYS - 53
