APRILIA SPORTCITY ONE 125 Service Station Manual

Fuel tank to chassis lateral fixing screw 10
•
Undo the screw «2».
Locking torques (N*m)
Fuel tank to chassis rear fixing screw 10
•
Loosen the two screws «3» placed in-
side the rear wheel well.
•
Disconnect the connector of the fuel
probe «4» and release the tank from
the pipes.
Front mudguard
•
Operating from both sides of the vehi-
cle, undo the three screws «1».
Chassis SPORTCITY ONE 125
CHAS - 168

APRILIA SPORTCITY ONE 125 Specifications

General

Engine Type	Single cylinder, 4-stroke
Displacement	124 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Front Suspension	Telescopic fork
Rear Suspension	Single shock absorber
Front Brake	Disc
Rear Brake	Drum
Front Tire	120/70 - 14
Rear Tire	120/70 - 14
Transmission	Automatic
Fuel Capacity	7 liters
