APRILIA SPORTCITY ONE 125 Service Station Manual

13. Coil
•
Remove the rear central cover to reach
it.
Characteristic
Coil primary resistance value:
~ 0.5 Ω
Coil secondary resistance value:
3000 ± 300 Ω
14. Pick-Up/Current generator/Oil pressure
sensor
•
The connector is placed under the ve-
hicle right fairing.
Characteristic
Pick-up resistance value:
~ 130 Ω
Generator phases resistance values:
1 ± 1 Ω
Generated current:
13A at 6000 rpm
15. Automatic starter
•
To reach the connector, remove the
right side fairing.
16. Start-up remote control switch
•
Remove the right side fairing to reach
it.
SPORTCITY ONE 125 Electrical system
ELE SYS - 47

APRILIA SPORTCITY ONE 125 Specifications

General

Engine Type	Single cylinder, 4-stroke
Displacement	124 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Front Suspension	Telescopic fork
Rear Suspension	Single shock absorber
Front Brake	Disc
Rear Brake	Drum
Front Tire	120/70 - 14
Rear Tire	120/70 - 14
Transmission	Automatic
Fuel Capacity	7 liters
