APRILIA SPORTCITY ONE 125 Service Station Manual

•
Remove the inspection latch from in-
side the helmet compartment.
•
Loosen the clamp «2».
Rear mudguard
•
Undo the two screws «1».
•
Undo the screw «2».
Helmet bay
•
Remove the saddle.
•
Remove the luggage rack.
•
Remove the rear central cover.
•
Remove the side fairings.
•
Undo the two screws «1» placed inside
the helmet compartment.
•
Remove the battery cover and the bat-
tery.
Chassis SPORTCITY ONE 125
CHAS - 166

APRILIA SPORTCITY ONE 125 Specifications

General

Engine Type	Single cylinder, 4-stroke
Displacement	124 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Front Suspension	Telescopic fork
Rear Suspension	Single shock absorber
Front Brake	Disc
Rear Brake	Drum
Front Tire	120/70 - 14
Rear Tire	120/70 - 14
Transmission	Automatic
Fuel Capacity	7 liters
