APRILIA SPORTCITY ONE 125 Service Station Manual

•
Remove the upper ring «3» of the up-
per bearing.
•
Slide the fork and collect the cage with
the balls of the upper bearing.
Locking torques (N*m)
Lower ring nut 13
•
Remove the balls retainer «7» of the
lower bearing from the steering tube .
•
Insert a punch inside the steering tube housing on the chassis and take out the bearing seats
on the chassis «5» e «6» by tapping with a hammer.
•
Carefully wash the bearings components.
•
Check wear status of the upper rings «2» and «6» and of the lower rings «5» and «8» of the
bearings.
•
To refit, carry out the removal operations but in reverse order:
•
Appropriately lubricate the bearings with recommended products.
Steering bearing
Checking bearing clearance
To check the steering, it is necessary to:
•
Park the vehicle on its centre stand.
•
Place the support under the scooter with a soft cloth between them so that the front wheel
can move freely and the scooter does not fall.
Suspensions SPORTCITY ONE 125
SUSP - 142

APRILIA SPORTCITY ONE 125 Specifications

General

Engine Type	Single cylinder, 4-stroke
Displacement	124 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Front Suspension	Telescopic fork
Rear Suspension	Single shock absorber
Front Brake	Disc
Rear Brake	Drum
Front Tire	120/70 - 14
Rear Tire	120/70 - 14
Transmission	Automatic
Fuel Capacity	7 liters
