17. Fuel level probe
•
Placed on the fuel tank.
Characteristic
Resistance value with empty tank
~ 101 Ω
Resistance value with full tank
~ 7.4 Ω
18. Diagnostics socket
•
Remove the battery cover to reach it.
Ground points
Ground point on chassis
•
Remove the rear central cover to reach
it.
Ground point on engine
•
Remove the helmet compartment to
reach it.
Checks and inspections
Electrical system SPORTCITY ONE 125
ELE SYS - 48
