Removing the oil sump

- Remove the oil filler plug, the transmission cover,

the complete drive pulley assembly with belt and

the sprocket wheel, as described in the Transmis-

sion chapter.

- Drain the oil from the sump as described above.

- Remove the 7 screws indicated in the figure and

the 2 rear brake transmission fixing brackets.

- Remove the spring, the by-pass piston and the

gasket shown in the second image.

Inspecting the by-pass valve

- Check the unloaded spring length.

- Check that the small piston is not scored.

- Ensure that it slides freely on the crankcase and

that it guarantees a good seal.

- If not, eliminate any impurities or replace defec-

tive parts.

Characteristic

By-pass check up: Standard length

54.2 mm

SPORTCITY ONE 125 Engine

ENG - 117
