THE CONTINUITY TEST SHOULD BE PERFORMED WITH THE RELATIVE CONNECTORS DIS-
CONNECTED.
•
Check continuity of the Green-Red cable between the 7.5A fuse B and stop buttons.
•
Check the stop buttons contacts.
•
Check continuity between the starter button Green-Red cable and the stop button Green-
Yellow cables.
•
Check the starter button contacts.
•
Check continuity between the Yellow-Red cable between the starter button and the start-up
remote control switch.
•
Check the start-up remote control switch.
•
Check continuity of the Red cable between remote control and the battery and between the
remote control and the starter motor.
•
Check that the starter motor is earthed.
Horn control
CAUTION
THE CONTINUITY TEST SHOULD BE PERFORMED WITH THE RELATIVE CONNECTORS DIS-
CONNECTED.
•
Check continuity of the Green cable which connects the horn button to 15A fuse C .
•
Check that the horn switch works properly.
•
Check continuity of the Grey cable which connects the switch to the horn.
Turn signals system check
CAUTION
THE CONTINUITY TEST SHOULD BE PERFORMED WITH THE RELATIVE CONNECTORS DIS-
CONNECTED.
•
Check that bulb operates properly.
•
Check continuity of the Green cable which connects turn indicators to the 15A fuse C .
•
With key switch set to «ON» check if there is intermittent voltage between the Blue-Black
cable and the turn indicators blinker Blue cable.
•
Check continuity of the Blue-Black cable between the turn indicators blinker and the turn
indicators switch.
•
Check that the turn indicator switch works properly.
•
Check continuity of the Red and Blue cables which connect the switch to the bulbs.
Electrical system SPORTCITY ONE 125
ELE SYS - 52
