APRILIA SPORTCITY ONE 125 Service Station Manual

Seat
•
Remove the four screws «1» shown in
figure and collect the washers.
Locking torques (N*m)
Saddle plate fixing nut 10
Rear rack
•
Remove the three screws «1» shown
in figure and collect the washers.
Locking torques (N*m)
Passenger handgrip fixing screw 20.5
Driving mirrors
•
Undo the screw «1» and remove the
rear view mirror.
•
Collect the cover and spacer.
Locking torques (N*m)
Mirror fixing screw 25
Chassis SPORTCITY ONE 125
CHAS - 158

APRILIA SPORTCITY ONE 125 Specifications

General

Engine Type	Single cylinder, 4-stroke
Displacement	124 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Front Suspension	Telescopic fork
Rear Suspension	Single shock absorber
Front Brake	Disc
Rear Brake	Drum
Front Tire	120/70 - 14
Rear Tire	120/70 - 14
Transmission	Automatic
Fuel Capacity	7 liters
