APRILIA SPORTCITY ONE 125 Service Station Manual

•
Working from the front wheel well in-
ternal side, undo the screw «2».
Knee-guard
•
Undo the twelve screws indicated and
remove the shield back plate.
•
Before fitting the shield back plate, re-
move the footrest fixing screws in order
to insert the two plastic parts.
NOTE
UPON FITTING, REMEMBER TO CONNECT THE FRONT
TOP BOX OPENING TRANSMISSION.
Front wheel housing
•
Remove the legshield.
•
Remove the front mudguard.
•
Remove the front wheel.
•
Undo the five screws «1».
SPORTCITY ONE 125 Chassis
CHAS - 161

APRILIA SPORTCITY ONE 125 Specifications

General

Engine Type	Single cylinder, 4-stroke
Displacement	124 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Front Suspension	Telescopic fork
Rear Suspension	Single shock absorber
Front Brake	Disc
Rear Brake	Drum
Front Tire	120/70 - 14
Rear Tire	120/70 - 14
Transmission	Automatic
Fuel Capacity	7 liters
