APRILIA SPORTCITY ONE 125 Service Station Manual

Refitting the driven pulley shaft bearing
- Heat up the crankcase inside with the hot air gun.
- Insert the bearing in its housing, refit the Seeger
ring.
NOTE
ALWAYS REPLACE THE BEARING WITH A NEW ONE
UPON REFITTING.
Specific tooling
020151Y Air heater
020376Y Adaptor handle
020357Y 32 x 35 mm adaptor
020412Y 15 mm guide
Removing the driven pulley
- Remove the spacer, the clutch bell and the whole
driven pulley unit.
NOTE
THE UNIT CAN ALSO BE REMOVED WITH THE DRIVING
PULLEY MOUNTED.
Inspecting the clutch drum
- Check that the clutch bell is not worn or damaged.
- Measure the clutch bell inside diameter.
Characteristic
Max. value clutch bell
Max. value: Ø 134.5 mm
Clutch bell standard value
Standard value: Ø 134 - 134.2 mm
Engine SPORTCITY ONE 125
ENG - 66

APRILIA SPORTCITY ONE 125 Specifications

General

Engine Type	Single cylinder, 4-stroke
Displacement	124 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Front Suspension	Telescopic fork
Rear Suspension	Single shock absorber
Front Brake	Disc
Rear Brake	Drum
Front Tire	120/70 - 14
Rear Tire	120/70 - 14
Transmission	Automatic
Fuel Capacity	7 liters
