Removing the carburettor

- To detach the carburettor from the engine, it is

necessary to move the air filter and remove the

throttle control transmission, the automatic starter

connection, the clamps anchoring the carburettor

to the filter housing and to the inlet manifold, the

air delivery pipe to the diaphragm, the heater, the

intake fitting and the TPS cable.

- Remove the heater

- Remove the protection, the bracket and the start-

er acting on the screw shown in the figure.

- Remove the 2 screws and the starter support with

the gasket.

SPORTCITY ONE 125 Engine

ENG - 119
